Hertz DCX 690.3 Dieci Series 6x9" 3-Way Coaxial Speakers

Hertz DCX 690.3 Dieci Series 6x9" 3-Way Coaxial Speakers

Hertz DCX 690.3 Dieci series car audio coaxials use an oversized magnetic group, TPU (Thermoplastic polyurethane) surround, a 60 mm diameter midrange, and a PEI dome tweeter. The result is linearity, wide dispersion, and extra-ordinary efficiency not found in traditional coax components. An involving, emotional sound, even at high SPL levels. An authentic 3-way coax capable of reproducing a wide frequency spectrum.

Technical Specifications
D mm: 170
Re Ohm: 3,4
Fs Hz: 66
Vas I: 25,7
Mms g: 16,5
Cms mm/N: 0,35
BL T*m: 3,9
Qts: 1,12
Qes: 1,55
Qms: 4,06
Spl dB: 93

Electro-acoustic Specifications
D mm: 170
Re Ohm: 3,4
Fs Hz: 66
Vas I: 25,7
Mms g: 16,5
Cms mm/N: 0,35
BL T*m: 3,9
Qts: 1,12
Qes: 1,55
Qms: 4,06
Spl dB: 93

Physical Specifications
DCX 690.3
A1: 237 mm (9.3 in.)
A2: 162 mm (6.4 in.)
B1: 224 mm (8.8 in.)
B2: 153 mm (6.0 in.)
C: 98 mm (3.9 in.)
D: 77 mm (3.0 in.)
